Brombach + Gess

PRODUCT PORTFOLIO



INNOVATIVE SOLUTIONS

Laminated safety glass for maritime requirements


  • High pressure load with thinner glass construction
  • Weight-reducing
  • All insulation and solar-filter coatings available

    Duromare

    safe & light

    Product description

    Brombach + Gess, in collaboration with the glass finisher Hero-Glas, has developed and licensed DUROmare laminated safety glass especially for maritime requirements. Laminated safety glass made from DUROmare can withstand higher pressure loads than a standard laminated glass pane. As a result, glass thicknesses can be significantly reduces, particularly where high load requirements result in glass thicknesses which are not available as single panes and therefore have to be manufactured as laminated glass.

    DUROmare is tested in accordance with the ISO 614 standard directives and is certified by the DNV GL classification company.

    This results in beneficial characteristics for shipyards and cruise line companies:

    WEIGHT-saving
    The thickness of the glass and thus the total weight of a glazing unit can be significantly reduced with DUROmare.

    MULTIfunctional
    Solar-filtering and heat protection requirements as well as sophisticated insulation can be factored into the DUROmare glass.

    In the following example, we compare standard insulating glass with solar-filtering and heat protection properties with type 86 DUROmare glass.

    Example

    Glass technology requirements

    Glass size:     1000 x 2000 mm
    Pressure load:         20 kPA
    Air conditioning requirements:
             Solar factor g value:                42%
             Thermal conductivity u value:  1.0 W/m²k


    Properties of the standard insulating glass
    Laminated glass comprising:
    19 mm of clear tempered safety glass (ESG),

    1.52 of PVB film,
    6 mm of sunguard 52,
    16 mm of argon (air gap),

    6 mm of ESG Climaguard 1.0

    Weight:         77.5 kg/m²









    Compared with

    Properties of type 86 DUROmare glass
    Laminated glass made from
    DUROmare 86,
    16 mm argon (LZR) and
    6 mm of ESG Climaguard 1.0


    Weight:         50 kg/m²



    DUROmare glass thus achieves a weight saving of 36% in comparison with the standard insulating glass.

    Ask us!

    We send information, give advice and answer questions all around your project

    More Information
